netCommander™ NPC-22T PDU provides secured remote power source management of 2 independent outlets with 2 serial console ports. Serial ports can be accessed independently and concurrently.
User: testme Pass: testme
Model Variations:
NPC-2201T - PDU features of NPC-22 with current sensor aggregated across all outlets
Features:
- 2 Independently managed power outlets.
- 2 Concurrent serial console ports.
- Status LEDs for each outlet, link LED and device power LED
- Configure and control with HTTP/HTTPS web interface or command line via Telnet / Serial
- Supports SSL V3.0 encryption for HTTPS access
- Use Autoping to reboot outlets after ping losses.
- Daily reboot or weekly scheduler for each outlet.
- Sync to NTP server or use real-time clock.
- Sends event notifications via email or view local event log.
- Restrict users to individual outlets as desired.
- Use external dial-up modem for backend solution (DB9 serial port)
- Optional 1U brackets for mounting on walls, under desk etc..
Specifications:
- 2 x NEMA 5-15R Outlets
- Handles up to 13A at 120VAC
- Compact enclosure: L 6.15" x W 5.40" x H 1.75"
- 1 x DB9 RS232 Port: Data: 7 or 8 bits. Stop Bits: 1 or 2. Parity: None Flow Control: None. Baud Rate: 2400 to 19200.
- 2 x DB9 RS232 User Ports: Data: 7 or 8 bits. Stop Bits: 1 or 2. Parity: None Flow Control: None. Baud Rate: 2400 to 19200.
- Network Protocols: ICMP, IP/TCP, NTP, SMTP, SNMP, DHCP, Telnet, HTTP/HTTPS and BootP
- Network Interface: 10/100-Base T. RJ-45.
- Operational Temperature Environment: -25C° → 50C°
- Humidity: 5-95%, non-condensing
- Safety and Compliance: cTUV(US & Canada), UL-60950, FCC Class B
Specifications
| Item | NPC-22T | NPC-22T01 |
|---|---|---|
| Physical Dimensions | 6.15” x 5.40” x 1.75” Compact | |
| Input Power Voltage | 120VAC, 60Hz | |
| Total Load (Combine all AC outlets) |
13 Amps Max | |
| Power Input | 1 - IEC 320 C14 | |
| AC Outlet Type | 2 - NEMA 5-15R | |
| AC Current Draw Monitoring | None | 1 - Input current sensor |
| Local Console Interface | 1 - RS232 Port. DB9 Connector. Data: 7 or 8 bits. Stop Bits: 1 or 2. Parity: None Flow Control: None. Baud Rate: 2400 to 115200 |
|
| User Console Interface | 2 - RS232 Port. DB9 Connector. Data: 7 or 8 bits. Stop Bits: 1 or 2. Parity: None Flow Control: None. Baud Rate: 2400 to 115200 |
|
| Network Interface | 10/100-Base T. RJ-45 | |
| Network Protocals | ICMP, IP/TCP, NTP, SMTP, SNMP, DHCP, Telnet, HTTPS/HTTP and BootP | |
| LED Indicators | 2 - Power outlet On/Off status LEDs 1 - Network LED 1 - Device Power LED |
|
| Weight | 2 lbs | |
| Operational Temperature | -25C° – 50C° | |
| Humidity | 5-95%, non-condensing | |
| UL/FCC Compliance | TUV(US), UL-60950, FCC Class B | |
